대리석 표면

Composite Materials

ECR roving for pultrusion & winding with unsaturated polyester, vinyl ester, and phenolic resins. It is widely applied to the building, communication, automotive, shipbuilding, and so on.

glass fiber roving.jpg
  • Linear Density [Tex] : 200, 300, 600, 1200, 2200, 2400, 4400, 4800, 8800

  • Breaking Strength : > 0.40 N/Tex  [Test Method - ISO 3341]

  • Filament Diameter : 17, 24 μm

  • LOI(Limiting Oxygen Index) : 0.4 - 0.5 %

Glass-fiber Mat for Roof Waterproofing

Raw material for the building waterproofing.

  • All of the product is based on ECR glass.

  • SBS/APP Bitumen Waterproof Membranes

  • Accessories for the Roof Waterproof coating

  • Asphalt shingles

wet-laid mat.png
아스팔트 슁글 구조.png

Advantage of HANA's Glass Fiber Mat on Asphalt Shingles

  • Including a more long filament structure gives better mechanical properties.

  • Less consumption of the asphalt compound gives the price competitiveness of the asphalt shingle.


Technical Data

wet mat 사양.png

What is ECR glass ?

E-glass vs. ECR-glass

  • E-glass is a means of "Electronic" glass. It has been developed for good water-resistance, insulation,
    and high mechanical strength. Most of the competitive manufacturers are using this E-glass.

  • To make easy E-glass production, manufacturers add 'B2O3' and 'Fluorine' in the glass batch during the process,

  • Particles of volatile B2O3 & fluorine get released into the atmosphere and this may cause serious human health issues.

Advantage of ECR-glass

  1. ECR glass is as same as E-glass but not including 'B2O3' and 'Fluorine'. Friendly to the environment.

  2. ECR glass has better mechanical strength than E-glass by 25 %. (Tensile Strength: 2,700 MPa [ASTM D2343] )

  3. The chemical resistance (including acid/alkali-resistance and sea-water resistance) is better than E-glass.

  4. Higher temperature resistance. The softening point of ECR glass is 40-500 C degrees higher than E-glass.

2020-02-05 12;00;28_.png
2020-02-05 14;07;22_.png
2020-02-05 14;10;27_.png
2020-02-05 14;10;11_.png
